NIFE-210-E11

NIFE-210-E11

NEXCOM
ART. NR.:: 10725200
Industrial Fieldbus Embedded System NIFE210-E11, Intel Celeron J6413 1.8GHz, DDR4, HDMI, DP, 2x2.5GbE LAN, 1xGbE LAN, 2xCOM, 2xUSB 3.0, 4xUSB 2.0, 1x2.5" Bay, mSATA, M.2, PCIe x4, 24VDC-in
Preis auf Anfrage
Verfügbar
Verfügbar
Power Adapter
Price inkl. MwSt.
Preis auf Anfrage
Power Adapter
Price inkl. MwSt.
Preis auf Anfrage
Aufbau
Gehäuse
Metallgehäuse mit Aluminium-Kühlkörper
Einbaumöglichkeit
Wall, Desktop
CPU
Installierter Prozessor
Celeron J6413
Maximale CPU-Frequenz
1.8 GHz
Schnittstelle
MicroSD Speicherkarten-Slots
1
Ethernet
Ethernet gesamt
3
10/100/1000 Mbit/s
3
Schnittstellen Seriell / Parallel
COM gesamt
2
RS-232/422/485
2
USB gesamt
6
Netzwerk
Industrieprotokolle
EtherCAT, EtherNet/IP, PROFINET, CANopen, DeviceNet, Profibus, Sercos III master
Schnittstellen
Schnittstellen
2xDB9, HDMI, 3xRJ45 Ethernet, 6xUSB, Display port, DC input (terminal block)
Maße und Gewicht
Breite
150 mm
Tiefe
157 mm
Höhe
232 mm
Systemleistung
Eingangsspannung DC
24..24 V
Betriebsbedingungen
Maximale Betriebstemperatur
-20..80 °C
Normen und Zertifikate
Zertifizierungen
CE, FCC Class A
EMS
EN 61000-6-2, EN 61000-6-4
Vibration und Schock
IEC 60068-2-27, IEC 60068-2-64
Maße
Bruttogewicht
2 kg
Nettogewicht
1.5 kg
Aufbau
Gehäuse
Metallgehäuse mit Aluminium-Kühlkörper
Einbaumöglichkeit
Wall, Desktop
CPU
Installierter Prozessor
Celeron J6413
Maximale CPU-Frequenz
1.8 GHz
Schnittstelle
MicroSD Speicherkarten-Slots
1
Ethernet
Ethernet gesamt
3
10/100/1000 Mbit/s
3
Schnittstellen Seriell / Parallel
COM gesamt
2
RS-232/422/485
2
USB gesamt
6
Netzwerk
Industrieprotokolle
EtherCAT, EtherNet/IP, PROFINET, CANopen, DeviceNet, Profibus, Sercos III master
Schnittstellen
Schnittstellen
2xDB9, HDMI, 3xRJ45 Ethernet, 6xUSB, Display port, DC input (terminal block)
Maße und Gewicht
Breite
150 mm
Tiefe
157 mm
Höhe
232 mm
Systemleistung
Eingangsspannung DC
24..24 V
Betriebsbedingungen
Maximale Betriebstemperatur
-20..80 °C
Normen und Zertifikate
Zertifizierungen
CE, FCC Class A
EMS
EN 61000-6-2, EN 61000-6-4
Vibration und Schock
IEC 60068-2-27, IEC 60068-2-64
Maße
Bruttogewicht
2 kg
Nettogewicht
1.5 kg
Aufbau
Gehäuse
Metallgehäuse mit Aluminium-Kühlkörper
Einbaumöglichkeit
Wall, Desktop
CPU
Installierter Prozessor
Celeron J6413
Maximale CPU-Frequenz
1.8 GHz
Schnittstelle
MicroSD Speicherkarten-Slots
1
Ethernet
Ethernet gesamt
3
10/100/1000 Mbit/s
3
Schnittstellen Seriell / Parallel
COM gesamt
2
RS-232/422/485
2
USB gesamt
6
Netzwerk
Industrieprotokolle
EtherCAT, EtherNet/IP, PROFINET, CANopen, DeviceNet, Profibus, Sercos III master
Schnittstellen
Schnittstellen
2xDB9, HDMI, 3xRJ45 Ethernet, 6xUSB, Display port, DC input (terminal block)
Maße und Gewicht
Breite
150 mm
Tiefe
157 mm
Höhe
232 mm
Systemleistung
Eingangsspannung DC
24..24 V
Betriebsbedingungen
Maximale Betriebstemperatur
-20..80 °C
Normen und Zertifikate
Zertifizierungen
CE, FCC Class A
EMS
EN 61000-6-2, EN 61000-6-4
Vibration und Schock
IEC 60068-2-27, IEC 60068-2-64
Maße
Bruttogewicht
2 kg
Nettogewicht
1.5 kg
Aufbau
Gehäuse
Metallgehäuse mit Aluminium-Kühlkörper
Einbaumöglichkeit
Wall, Desktop
CPU
Installierter Prozessor
Celeron J6413
Maximale CPU-Frequenz
1.8 GHz
Schnittstelle
MicroSD Speicherkarten-Slots
1
Ethernet
Ethernet gesamt
3
10/100/1000 Mbit/s
3
Schnittstellen Seriell / Parallel
COM gesamt
2
RS-232/422/485
2
USB gesamt
6
Netzwerk
Industrieprotokolle
EtherCAT, EtherNet/IP, PROFINET, CANopen, DeviceNet, Profibus, Sercos III master
Schnittstellen
Schnittstellen
2xDB9, HDMI, 3xRJ45 Ethernet, 6xUSB, Display port, DC input (terminal block)
Maße und Gewicht
Breite
150 mm
Tiefe
157 mm
Höhe
232 mm
Systemleistung
Eingangsspannung DC
24..24 V
Betriebsbedingungen
Maximale Betriebstemperatur
-20..80 °C
Normen und Zertifikate
Zertifizierungen
CE, FCC Class A
EMS
EN 61000-6-2, EN 61000-6-4
Vibration und Schock
IEC 60068-2-27, IEC 60068-2-64
Maße
Bruttogewicht
2 kg
Nettogewicht
1.5 kg
Dokumente
NIFE-210-E11-E12-Datasheet-10092024.pdf NIFE-210-E11-E12-User-Manual-October-2024.pdf
Dokumente
NIFE-210-E11-E12-Datasheet-10092024.pdf NIFE-210-E11-E12-User-Manual-October-2024.pdf
Dokumente
NIFE-210-E11-E12-Datasheet-10092024.pdf NIFE-210-E11-E12-User-Manual-October-2024.pdf
Dokumente
NIFE-210-E11-E12-Datasheet-10092024.pdf NIFE-210-E11-E12-User-Manual-October-2024.pdf
