Name: AEC-8000-MSKU
Brand: Arbor
SKU: 80276900
Price: 120972.96 EUR
Availability: PreOrder

Home

Catalog

Industrie PCs

Embedded Edge PCs, Industrie Box PCs und Mini-PCs

Embedded PCs mit diskreter GPU und KI Accelerator

AEC-8000-MSKU

Arbor

ART. NR.:: 80276900

Embedded Edge AI System, NVIDIA Jetson Thor T5000 14-Core CPU, 128GB LPDDR5x RAM, Blackwell 2650-Core GPU, 2xHDMI, 2xGbE LAN, 1x100GbE QSFP, 4xUSB 3.2, 2xUSB-C 3.2 DP/OTG, 2xCOM, 4xCAN, 16-bit GPIO, 1xM.2 Key-M, 1xM.2 Key-B, 1xM.2 Key-E, 9-36VDC-in

Preis auf Anfrage

Aufbau

Gehäuse

Metallgehäuse

Einbaumöglichkeit

Wall

Typ

Mehrere Lüfter

CPU

Installierter Prozessor

Nvidia Jetson T5000

Socket

CPU onboard

Maximale CPU-Frequenz

2.6 GHz

Chipsatz

SoC

Speicher

Formfaktor

DDR5

Socket Typ

Verlötet

ECC

Yes

Standard Onboard Speicher

128 GB

Bauweise

Onboard fixiert

Grafik

Grafikcontroller

NVIDIA Blackwell, 2560-cores, 96 Tensor Cores

Schnitstellen

2xHDMI

Ethernet

Ethernet gesamt

10/100/1000 Mbit/s

SFP 100/1000 Mbit/s Ports

Wi-Fi

WLAN IEEE-Norm

Yes (Optional)

Schnittstellen Seriell / Parallel

COM gesamt

RS-232/422/485

USB gesamt

USB v3.x

Digital Eingang / Ausgang

Gesamtanzahl

Industrie Protokolle

CAN Port

Schnittstelle

M.2

Steckplätze

Gesamtanzahl

M.2

M.2 Formfaktor

3042 M, 2280 M, 2230 E, 3052 B

SIM-Karten Steckplätze

Yes, 2, Micro-SIM

Antennen Eigenschaften

Mobilfunk

4G (Optional)

Status LEDs / Schalter

LED

Power LED

Schalter

On/Off, 1xReset

Schnittstellen

2xDB9, 2xHDMI, 2xRJ45 Ethernet, 4xUSB, Mic In, Line Out, DC input (terminal block), DB9 DIO, 2xSIM Card Slot, 2xCAN (terminal block), 1xSFP, 3xUSB type C

Stromversorgung

Eingangsspannung DC

9..36 V

Netzteil

Unterstützte Stromversorgung

External power adapter AC/DC

Software

Betriebssystemkompatibilität

Ubuntu, NVIDIA Jetpack

Maße und Gewicht

Breite

211 mm

Höhe

111 mm

Tiefe

194 mm

Betriebsbedingungen

Maximale Betriebstemperatur

-25..50 °C

Luftfeuchtigkeit

5-95%

Normen und Zertifikate

Zertifizierungen

CE, FCC, EN50155/50121

MIL-STD-810

MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810H Test Method 516.8 Shock

Maße

Bruttogewicht

5.2 kg

Nettogewicht

4 kg

Dokumente

AEC‑8000-Series-Datasheet.pdf
