Name: EG2-1002-10GSFP
Brand: Leonton
SKU: 80120600
Price: 498.04 EUR
Availability: PreOrder

Home

Catalog

Industrielle Kommunikation

Industrielle Ethernet Switches

DIN-Rail Managed Switches

EG2-1002-10GSFP

Leonton

ART. NR.:: 80120600

Industrial Ethernet Switch, IP30, 8x10/100/1000Base-TX, 2x10GBase-X SFP+, Dual 12..48VDC, Operating Temperature -40..65 C

Preis auf Anfrage

Ethernet

Ethernet gesamt

10/100/1000 Mbit/s

10 Gbit SFP+ Ports

Switch Properties

MAC Table Size

16000

Jumbo Frame Size

9.6 kB

Netzwerk

IEEE Norm

IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3x for Flow Control, IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.3u for 100BaseT(X)

Systemleistung

Eingangsspannung DC

12..48 V

Aufbau

Schutzlevel Gehäuse

IP30

Maße und Gewicht

Breite

54 mm

Tiefe

142 mm

Höhe

99 mm

Betriebsbedingungen

Maximale Betriebstemperatur

-40..65 °C

Luftfeuchtigkeit

5-95%

Normen und Zertifikate

EMI

FCC Part 15 Subpart B Class A

EMS

IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-6-2, EN 61000-6-4

Internetsicherheit

UL 61010-2-201

Sturz

IEC 60068-2-32

Vibration und Schock

IEC 60068-2-6, IEC 60068-2-27

Maße

Bruttogewicht

1.34 kg

Nettogewicht

1.1 kg

Ethernet

Ethernet gesamt

10/100/1000 Mbit/s

10 Gbit SFP+ Ports

Switch Properties

MAC Table Size

16000

Jumbo Frame Size

9.6 kB

Netzwerk

IEEE Norm

IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3x for Flow Control, IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.3u for 100BaseT(X)

Systemleistung

Eingangsspannung DC

12..48 V

Aufbau

Schutzlevel Gehäuse

IP30

Maße und Gewicht

Breite

54 mm

Tiefe

142 mm

Höhe

99 mm

Betriebsbedingungen

Maximale Betriebstemperatur

-40..65 °C

Luftfeuchtigkeit

5-95%

Normen und Zertifikate

EMI

FCC Part 15 Subpart B Class A

EMS

IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-6-2, EN 61000-6-4

Internetsicherheit

UL 61010-2-201

Sturz

IEC 60068-2-32

Vibration und Schock

IEC 60068-2-6, IEC 60068-2-27

Maße

Bruttogewicht

1.34 kg

Nettogewicht

1.1 kg

Ethernet

Ethernet gesamt

10/100/1000 Mbit/s

10 Gbit SFP+ Ports

Switch Properties

MAC Table Size

16000

Jumbo Frame Size

9.6 kB

Netzwerk

IEEE Norm

IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3x for Flow Control, IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.3u for 100BaseT(X)

Systemleistung

Eingangsspannung DC

12..48 V

Aufbau

Schutzlevel Gehäuse

IP30

Maße und Gewicht

Breite

54 mm

Tiefe

142 mm

Höhe

99 mm

Betriebsbedingungen

Maximale Betriebstemperatur

-40..65 °C

Luftfeuchtigkeit

5-95%

Normen und Zertifikate

EMI

FCC Part 15 Subpart B Class A

EMS

IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-6-2, EN 61000-6-4

Internetsicherheit

UL 61010-2-201

Sturz

IEC 60068-2-32

Vibration und Schock

IEC 60068-2-6, IEC 60068-2-27

Maße

Bruttogewicht

1.34 kg

Nettogewicht

1.1 kg

Ethernet

Ethernet gesamt

10/100/1000 Mbit/s

10 Gbit SFP+ Ports

Switch Properties

MAC Table Size

16000

Jumbo Frame Size

9.6 kB

Netzwerk

IEEE Norm

IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3x for Flow Control, IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.3u for 100BaseT(X)

Systemleistung

Eingangsspannung DC

12..48 V

Aufbau

Schutzlevel Gehäuse

IP30

Maße und Gewicht

Breite

54 mm

Tiefe

142 mm

Höhe

99 mm

Betriebsbedingungen

Maximale Betriebstemperatur

-40..65 °C

Luftfeuchtigkeit

5-95%

Normen und Zertifikate

EMI

FCC Part 15 Subpart B Class A

EMS

IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-6-2, EN 61000-6-4

Internetsicherheit

UL 61010-2-201

Sturz

IEC 60068-2-32

Vibration und Schock

IEC 60068-2-6, IEC 60068-2-27

Maße

Bruttogewicht

1.34 kg

Nettogewicht

1.1 kg

Dokumente

EG2-1002-10GSFP-Datasheet.pdf

Dokumente

EG2-1002-10GSFP-Datasheet.pdf

Dokumente

EG2-1002-10GSFP-Datasheet.pdf

Dokumente

EG2-1002-10GSFP-Datasheet.pdf

Produktanfrage

EG2-1002-10GSFP

Leonton

ART. NR.:: 80120600
