XGS-6350-16X8Y4C

ART. NR.:: 80263300

Managed L3 Ethernet Switch, 1x10/100/1000Base-T, 16x10GBase-SR/LR SFP+, 8x25G SFP28, 4x100G QSFP28, 1xUSB, 100..240V AC, Operating Temperature 0..50C

Preis auf Anfrage

Ethernet

10/100/1000 Mbit/s

10 Gbit SFP+ Ports

QSFP+ 100 Gigabit/s Ethernet

Switch Properties

Jumbo Frame Size

12 kB

Netzwerk

Protokoll Layer 3

VRRP, Static Routing, RIP V1/V2, OSPF, PIM-DM, PIM-SM, PIM-SSM, BGP

Steuerungsprotokolle

SNMPv1/v2c/v3, Telnet, DHCP, NTP, GVRP, TFTP, LACP, CoS, FTP, IGMP Snooping v1/v2/v3, ICMP

Reservierungs-Protokolle

MSTP, STP, RSTP

Sicherheitsprotokolle

RADIUS, SSL, TACACS+, SSH2

IEEE Norm

ieee_802.3ae, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3ad for Port Trunk with LACP, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX

Systemleistung

Eingangsspannung AC

100..240 V

Maße und Gewicht

Breite

442.5 mm

Tiefe

280.25 mm

Höhe

44.6 mm

Betriebsbedingungen

Maximale Betriebstemperatur

0..50 °C

Normen und Zertifikate

Zertifizierungen

CE, FCC Class A

Maße

Bruttogewicht

5 kg

Nettogewicht

4.3 kg

Ethernet

10/100/1000 Mbit/s

10 Gbit SFP+ Ports

QSFP+ 100 Gigabit/s Ethernet

Switch Properties

Jumbo Frame Size

12 kB

Netzwerk

Protokoll Layer 3

VRRP, Static Routing, RIP V1/V2, OSPF, PIM-DM, PIM-SM, PIM-SSM, BGP

Steuerungsprotokolle

SNMPv1/v2c/v3, Telnet, DHCP, NTP, GVRP, TFTP, LACP, CoS, FTP, IGMP Snooping v1/v2/v3, ICMP

Reservierungs-Protokolle

MSTP, STP, RSTP
