IGS-12040MT

Name:

Planet Technology Corporation

Ethernet gesamt:

12

10/100/1000 Mbit/s:

8

SFP Gigabit Ethernet 100/1000 Mbit/s:

4

Managed:

Yes, Layer 2, Layer 3

Netzwerkprotokoll:

LLDP, Telnet, SNMP, NTP, IGMP Snooping v1/v2/v3, IGMP Querier

Protokoll Layer 3:

Static Routing

IEEE Norm:

IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3ad for Port Trunk with LACP, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX (IEEE 802.1ab для LLDP, IEEE 802.3ah для OAM, IEEE 802.1ag для Connectivity Fault Management(CFM), IEEE 1588 для PTPv2, RFC 768 UDP, RFC 793 TFTP, RFC 791 IP, RFC 792 ICMP, RFC 2068 HTTP, RFC 1112 IGMPv1, RFC 2236 IGMPv2, RFC 3376 IGMPv3, RFC 2710 MLDv1, R)

IP Version:

IPv4, IPv6

Verschlüsselung:

SSH, SSL (TLS v1.2)

MAC Table Size:

8000 (automatic source address learning and ageing)

DRAM Size:

128 MB

Priority Queues:

8

Max. Number of VLANs:

255

VLAN ID Range:

1 - 4095

IGMP Groups:

255

Jumbo Frame Size:

9 kB

Supported technologies:

QoS

Supported functions:

Port Mirror, Rate Limit, Loop Protection, Broadcast Storm Protection, Link Aggregation, Automatic power failure notification, Automatic port failure notification, Flow Control, Back pressure flow control, Access Control Lists, MAC ACL, Ring Operation

Gesamtanzahl:

2

Gesamtanzahl:

2

Typ:

Lüfterlos

LED:

LED Panel, 1xOn/Off LED, Power LED, Power Fail, LAN LED

Schalter:

1xReset

Schnittstellen:

RJ45 (Console)

Eingangsspannung DC:

12 ... 72 V

Eingangsspannung AC:

24 ... 24 V

Temperatur:

-40 ... 75 °C ((-10 ~ 60 degrees C for AC power input))

Feuchtigkeit:

5 ... 95 % (non-condensing)

MTBF:

100000 (@ 25 degrees C)

Temperaturbereich:

-40 ... 85 °C

Feuchtigkeit:

5 ... 95 % (non-condensing)

Gehäuse:

Aluminiumgehäuse

Einbaumöglichkeit:

Wall, DIN-Rail mount

Schutzlevel Gehäuse:

IP30

Breite:

76.8 mm

Höhe:

152 mm

Tiefe:

107.3 mm

Zertifizierungen:

CE, FCC Class A

Vibration und Schock:

IEC 60068-2-6, IEC 60068-2-27

Sturz:

IEC 60068-2-32

EMI:

FCC Part 15 Subpart B Class A
