UPOE-1600XG

Planet
ART. NR.:: 80269300
Managed Injector Hub, 16x10/100/1000/2.5G/5G/10GBase-T RJ-45 with PoE++, 100..240 VAC, Operating Temperature 0..50 C
Preis auf Anfrage
Verfügbar
Verfügbar

Ethernet
Ethernet gesamt
16
10 Gbit/s
16
PoE+ 10/100/1000 Mbit/s
16
Power Budget
600 W
Netzwerk
Steuerungsprotokolle
SNMPv1/v2c/v3, HTTP, LLDP, Syslog, SNMP, NTP, DDNS
Sicherheitsprotokolle
HTTPS, RADIUS
IEEE Norm
IEEE 802.3 for 10BaseT, IEEE 802.3ad for Port Trunk with LACP, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X), IEEE 802.3bz for 5GBaseT and 2.5GBaseT, IEEE 802.3bt for Power over Ethernet
Stromversorgung
Eingangsspannung AC
100..240 V
Maße und Gewicht
Breite
440 mm
Tiefe
301 mm
Höhe
44 mm
Betriebsbedingungen
Maximale Betriebstemperatur
0..50 °C
Luftfeuchtigkeit
5-90%
Normen und Zertifikate
Zertifizierungen
CE
EMI
FCC Part 15 Subpart B Class A
Maße
Bruttogewicht
5 kg
Nettogewicht
4.4 kg
Ethernet
