U-7560M
ICP DAS
ART. NR.:: 09374800
OPC UA I/O Module with 6-ch DI, 6-ch Relay 5 A @ 250 VAC/24 VDC, and 2-port Ethernet Switch (RoHS)
Preis auf Anfrage
Verfügbar auf Bestellung
Verfügbar auf Bestellung
Aufbau
Gehäuse
Metallgehäuse
Einbaumöglichkeit
Wall
Ethernet
10/100 Mbit/s
2
Netzwerk
Industrieprotokolle
MQTT client
Digital Eingang
Gesamtanzahl
6
Typ
Wet contact
Pegel der Logik "0"
0~4 V
Pegel der Logik "1"
10~50 V
Sink/Source
Stromziehend (Sink), stromliefernd (Source)
Zähler
50 Hz, 16 bit
Digital Ausgang
Gesamtanzahl
6
Typ
Electromagnetic relay
Max. Strom für Relaiskontakte
5A@250V AC, 5A@28V DC
Systemleistung
Eingangsspannung DC
12..48 V
Power over Ethernet (PoE)
PoE
Maße und Gewicht
Breite
92 mm
Tiefe
42 mm
Höhe
120 mm
Betriebsbedingungen
Maximale Betriebstemperatur
-25..75 °C
Normen und Zertifikate
EMS
IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5
Maße
Bruttogewicht
0.35 kg
Nettogewicht
0.2 kg
