NS-205

NS-205

ICP DAS
ART. NR.:: 02680700
Industrial Smart Ethernet Switch with 5 10/100 Base-T Ports
Preis auf Anfrage
Verfügbar
Verfügbar
Ethernet
Ethernet gesamt
5
10/100 Mbit/s
5
10/100 Mbit/s Schnittstelle
5xRJ-45
Switch Properties
Managed
No
Switch Level
Layer 2
Netzwerk
IEEE Norm
IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control
Systemleistung
Eingangsspannung DC
10..30 V
Aufbau
Gehäuse
Kunststoffgehäuse
Einbaumöglichkeit
DIN-Rail mount
Maße und Gewicht
Breite
33 mm
Tiefe
78 mm
Höhe
107 mm
Betriebsbedingungen
Maximale Betriebstemperatur
-40..75 °C
Normen und Zertifikate
Zertifizierungen
CE, WEEE, FCC
Maße
Bruttogewicht
0.19 kg
Nettogewicht
0.19 kg
Ethernet
Ethernet gesamt
5
10/100 Mbit/s
5
10/100 Mbit/s Schnittstelle
5xRJ-45
Switch Properties
Managed
No
Switch Level
Layer 2
Netzwerk
IEEE Norm
IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control
Systemleistung
Eingangsspannung DC
10..30 V
Aufbau
Gehäuse
Kunststoffgehäuse
Einbaumöglichkeit
DIN-Rail mount
Maße und Gewicht
Breite
33 mm
Tiefe
78 mm
Höhe
107 mm
Betriebsbedingungen
Maximale Betriebstemperatur
-40..75 °C
Normen und Zertifikate
Zertifizierungen
CE, WEEE, FCC
Maße
Bruttogewicht
0.19 kg
Nettogewicht
0.19 kg
Ethernet
Ethernet gesamt
5
10/100 Mbit/s
5
10/100 Mbit/s Schnittstelle
5xRJ-45
Switch Properties
Managed
No
Switch Level
Layer 2
Netzwerk
IEEE Norm
IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control
Systemleistung
Eingangsspannung DC
10..30 V
Aufbau
Gehäuse
Kunststoffgehäuse
Einbaumöglichkeit
DIN-Rail mount
Maße und Gewicht
Breite
33 mm
Tiefe
78 mm
Höhe
107 mm
Betriebsbedingungen
Maximale Betriebstemperatur
-40..75 °C
Normen und Zertifikate
Zertifizierungen
CE, WEEE, FCC
Maße
Bruttogewicht
0.19 kg
Nettogewicht
0.19 kg
Ethernet
Ethernet gesamt
5
10/100 Mbit/s
5
10/100 Mbit/s Schnittstelle
5xRJ-45
Switch Properties
Managed
No
Switch Level
Layer 2
Netzwerk
IEEE Norm
IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control
Systemleistung
Eingangsspannung DC
10..30 V
Aufbau
Gehäuse
Kunststoffgehäuse
Einbaumöglichkeit
DIN-Rail mount
Maße und Gewicht
Breite
33 mm
Tiefe
78 mm
Höhe
107 mm
Betriebsbedingungen
Maximale Betriebstemperatur
-40..75 °C
Normen und Zertifikate
Zertifizierungen
CE, WEEE, FCC
Maße
Bruttogewicht
0.19 kg
Nettogewicht
0.19 kg
Dokumente
Datasheet_ns_205_105A__23239059.pdf NS_205_Usermanual__31267591.pdf
Dokumente
Datasheet_ns_205_105A__23239059.pdf NS_205_Usermanual__31267591.pdf
Dokumente
Datasheet_ns_205_105A__23239059.pdf NS_205_Usermanual__31267591.pdf
Dokumente
Datasheet_ns_205_105A__23239059.pdf NS_205_Usermanual__31267591.pdf
